SC570 | Surface Contact | Grade 3 | Brown | Non-resistored

SKU SC570/BR/G3/EN Category

6 Terminals
Cover and wall tamper
Available in white, brown or anthracite grey
Magnetic Detection
EN50131-2-6 Grade 3
Environmental Class II

Description

This magnetic door contact can be used in most security systems up to and including grade 3 and environmental class II as specified in EN50131-1 and is certified to EN50131-2-6 by Kiwa FSS.
It operates as a normally-closed circuit which opens when the magnet housing is moved away from the contact housing. This contact can be used on windows and doors to detect the unauthorised entry of an intruder. The contact is also protected against tampering with optional detection of removal from its mounting surface. Additionally there is a magnetic interference detection circuit for signalling the proximity of a magnet, which is typically used by an intruder trying to inhibit the performance of the contact.

Additional information

Colour

Brown

Material

HIPS

Contact Material

Rhodium & Ruthenium

Commodity Code

85311030

Country Of Origin

UK

Height (mm)

20

Width (mm)

40

Depth (mm)

84

Barcode

5060399128070

Weight (kg)

0.025

Type of

Surface

EN50131-2-6 Grade

3

Tamper Protection

Cover RFMS & MID

EN50130-5 class

Class II

IP Rating

4X

Temperature Range

-15°C – +40°C

Contact Dimensions (mm)

85 x 25 x 21

Magnet Dimensions (mm)

85 x 25 x 21

Maximum switching voltage (Vdc)

12Vdc

Maximum switching current (mA)

500

Connection Type

Wired

No. of Terminals

6 Terminal

Contact Type

Normally Closed

Mode Of Operation

DP

Operation Axes (X, Y, Z)

X, Y

Pull-in gap (X, Y, Z)mm

12, 10

Pull in Gap

10mm

Suitable for Double Door

Yes

Suitable for Double Pole Sys

Yes

No of Reed Switches

1

Resistor Value

Non-resistored

Datasheet
Declaration of Performance EU
