SC555 | Surface Contact | Grade 2 | Aluminium | Non-resistored

SKU SC555/AL/4CX Category

4 Core pre-wired
15mm operating gap
EN50131-2-6 Grade 2
Environmental Class II
Size 43 x 17 x 19mmn

Description

This surface mounted magnet contact can be used in security systems up to and including grade 2 and environmental class II as specified in EN50131-1 and is compliant with EN50131-2-6.
It operates as a normally closed circuit going open when the magnet is removed. This contact is not suitable for ferrous surfaces

Additional information

Colour

Aluminium

Material

Aluminium

Contact Material

Rhodium

Commodity Code

85311030

Country Of Origin

UK

Height (mm)

15

Width (mm)

82

Depth (mm)

72

Barcode

5.0604E+12

Weight (kg)

0.05797

Type of

Pre-wired

EN50131-2-6 Grade

2

Tamper Protection

Internal

EN50130-5 class

Class II

IP Rating

3X

Temperature Range

-10°C – +40°C

Contact Dimensions (mm)

35 x 15 x 10

Magnet Dimensions (mm)

35 x 15 x 10

Maximum switching voltage (Vdc)

less than50Vdc

Maximum switching current (mA)

500

Connection Type

Wired

No. of Terminals

4 Wire

Contact Type

Normally Closed

Wire length (mm)

1000

Mode Of Operation

DP

Pull-in gap (X, Y, Z)mm

15, 15

Pull in Gap

15mm

Suitable for Double Door

Yes

Suitable for Double Pole Sys

Yes

No of Reed Switches

1

Resistor Value

Non-resistored

Datasheet
Declaration of Performance EU
