RS002 | Roller Shutter Contact | Grade 2 | Aluminium | Non-resistored

SKU RS002/ALI Category

High Quality Alloy Finish
Double pole
EN50131-2-6 Grade 2
Environmental Class III

Description

This roller shutter contact can be used in most security systems up to and including grade 2 as specified in EN50131-1:2006+A3:2020 and is compliant with EN50131-2-6:2008 and environmental class III.
It is designed to work with control panels that require a normally closed circuit going open in alarm and also has a 450mm of armoured cable to allow for connection to a suitable junction box. It has a single reed switch and a tamper loop, this contact can be used on roller shutter doors to detect the unauthorised entry of an intruder. The contact is potted/sealed to prevent access to the inside of the contact.

Additional information

Colour

Aluminium

Material

Aluminium

Contact Material

Ruthenium

Height (mm)

10

Width (mm)

50

Depth (mm)

200

Barcode

5.0604E+12

Weight (kg)

0.38

Type of

Roller Shutter

EN50131-2-6 Grade

2

Tamper Protection

Internal

EN50130-5 class

Class III

IP Rating

32

Temperature Range

-10°C – +40°C

Contact Dimensions (mm)

80 x 71 x 30

Magnet Dimensions (mm)

80 x 71 x 30

Maximum switching voltage (Vdc)

less than50Vdc

Maximum switching current (mA)

500

Connection Type

Wired

No. of Terminals

4 Wire

Contact Type

Normally Closed

Wire length (mm)

450

Mode Of Operation

DP

Operation Axes (X, Y, Z)

X, Y

Pull-in gap (X, Y, Z)mm

25, 50

Pull in Gap

50mm

Suitable for Double Door

Yes

Suitable for Double Pole Sys

Yes

No of Reed Switches

1

Resistor Value

Non-resistored
