Panic Button | Electronic | Grade 2/3 | White | Key Resetable

SKU EPA/STD Category

8 Terminals
Electronic 12V (45mA) Dual Push
Key Resettable
LED Indicator
Self Latching
Rear Tamper

Description

The original electronic Hold-up device is still available. This is a flush – fitting Hold-up device which means that the device can be mounted in a standard UK gang box, thanks to its flat face and resessed buttons.

Additional information

Colour

White

Buttons

Dual Push

Reset Method

Key

Switch rating

12v 1A

PA Output

Changeover COM/NO/NC

Commodity Code

85311030

Country Of Origin

UK

Height (mm)

62

Width (mm)

95

Depth (mm)

95

Barcode

5060399126083

Weight (kg)

0.1467

EN50131-1 Grade

3

Tamper Protection

RFMS Spring

EN50130-5 class

II

IP Rating

4X

Temperature Range

-10° C to +40° C

Material

ABS

Dimensions (mm)

85 x 85 x 16

Voltage range (Vdc)

12

Nominal voltage (Vdc)

12

Quiescent Current (mA)

45

Visual Indication

Yes

Reset Option

Latching

Confirmed Output

No

Operation Mode

Push

Timed

No

Mounting method

Surface / Flush

Connection Type

Terminals

No. Terminals

8

Other Standards

PD6662 & BS4737 3.14 Type Z

Datasheet
Declaration of Conformity
