100% copper cores
Easy to strip & pliable in use
Coloured rip cord for BS4737 identification
EN50575 CPR certified
Our range of intruder alarm cables is designed to set the industry benchmark, providing market-leading levels of low resistance, core strength and ease of installation. Available in PVC / Low smoke and Fume (LSF) and Low Smoke Zero Halogen (LSZH) variants, ensuring compliance with even the most sensitive of installation requirements.
| Number of Cores | 4 |
|---|---|
| Multi or Solid | Multi |
| BS4737 Type | TYPE 2 |
| EURO CLASS | Eca |
| Length (Mtrs) | 500 |
| Sheathing | PVC |
| Sheathing Colour | White |
| Screened | No |
| Conductor Type | Tinned Copper |
| Conductor Size | 0.182 |
| Number of Strands in Core | 7 |
| CSA (mm²) | 0.182 |
| AWG | 25 |
| Insulation Material | PVC |
| Insulation Colour | RD-BK-YL-BL |
| Insulation Resistance @20°C | ≥ 200 MΩ/Km |
| Nominal Diameter | 3.4mm |
| Max Voltage | 50V |
| Resistance (Ω/km) | 94.6 |
